Heat and Noise Reduction Heat Shield is press lined thermal foam rubber material using our E-TAC formula which is 1mm thick aluminium foil layer. It reduces up to 70% of direct heat making one of the most effective easy to apply peal and stick heat barriers on the market. Effective up to 160°c the demand for our high quality heatshield has seen its way through endless applications.
This will help ensure a cool lifestyle, on the road, in the factory, on the water or on the farm while saving money, time and energy. Though this product is designed to predominantly offer thermal protection, it can also drown out noise to a certain extent, thanks to the fibrous, organic core layer that captures and eliminates some of the sound waves that try to creep up into a cabin.
Produced and tested specifically for South Africa’s harsh climate and we can guarantee your satisfaction in our product.
APPLICATIONS
- Automotive, Marine & Agricultural
- Under Hood of vehicle or boat
- Firewall of the vehicle or boat in the engine bay
- Building Thermal Insulation Material
- Corrugated Roof Underlay
- Stud Wall, Metal Frame Building Insulation.
- Industrial
- Protective coatings of ducts & pipes
- Shells of air conditioner and water heater.
- Generator boxes/rooms
INSTALLATION
- Use scissors, knife or die to cut material to the desired size.
- Remove dust, grease and moisture from the surface.
- Peel off the backing.
- The simplest application technique is to bend the mat slightly and attach it along its shortest edge.
- Press the mat firmly into place.
- The roller reduces the risk of leaving air pockets, which reduce material’s sound damping capacity.
- Heating the material is NOT necessary.
- Work gloves should be used when handle foil backed material because the sharp edges when cut to different size.
SPECIFICATIONS
Appearance:
Dark grey closed cell foam with aluminium foil facing.
Thickness:
6mm
Aluminium Foil Thickness:
1mm
Weight:
0.059 (kg /m³)
Density:
0.90 (kg /m³)
Tensile Strength:
≥19 KPa
Tear Strength:
2.4
Test: Stop Noise in vehicle:
Install in the vehicle hood to stop noise rate ≥4.2dB
Test: Stop Heat in vehicle:
Install in the vehicle hood, heat insulation rate ≥48%
Temperature Range:
-40°C to +120°C
Chemical Resistance:
Resistant to water and mineral oils
ISO Approved:
ISO2001: 2008
Storage Information: Number of Rolls in Box:
1 roll per box.
TECHNICAL INFORMATION
Coverage per sheet:
1.1m2
Weight per sheet:
2.2 kg
Dimensions per sheet:
813mm x 1372mm
Heat Shield Uses:
NOISE REDUCTION USES
Though this product is designed to predominantly offer thermal protection, it can also drown out noise to a certain extent, thanks to the fibrous, organic core layer that captures and eliminates some of the sound waves that try to creep up into a cabin.
THERMAL INSULATION
Heat Shield is the best thermal insulation mat we offer.
This self-adhesive barrier is designed to face the heat source directly to reflect radiant heat and dissipate convectional heat up to 400 degrees c.
This self-adhesive barrier is designed to face the heat source directly to reflect radiant heat and dissipate convectional heat up to 400 degrees c.
What are the most common and most effective uses for Heat Shield?
Most people like to use Heat Shield under their bonnet or on their firewall, but it also works great for blocking exhaust heat. Really anywhere you can apply Heat Shield facing a heat source is an effective place to apply it.
